Wharfedale CPD3600 2x 870-Watt Power Amplifier
Wharfedale CPD3600 2x 870-Watt Power Amplifier
The Wharfedale CPD3600 Power amplifier delivers 870W RMS per channel at 8 Ohms and 1300W RMS per channel at 4 Ohms; a suitable power for medium to large sized complete PA systems for mobile and fixed installation. In bridged mode at 4 Ohms the amplifier generates 3600W RMS. This huge power means the amplifier can also integrate itself with larger touring rigs and installs where long throw, extremely high power audio is needed.
Technology
Working in stereo, parallel and bridged modes CPD3600 is built for a multitude of sound system formations. Brand new class H topology has resulted in a dynamic, high headroom amp made for propelling your loudspeakers through thick and thin with complete clarity.
Precision Control
Large rotary dials accurately adjust gain levels, and you will know when to do so from the clear and simple front panel. A 4 segment led formation displays shows vital power status, level, limit and protect information, keeping the sound engineer in the know.
Easy Cleaning
Amplifiers often work in hot and dusty environments and, over time, the fans of an amplifier can easily suck this in. Dirty cooling fans reduce efficiency and can lead to overheating. Its for this reason that Wharfedale Pro made the CPD series easy to clean. Simply unscrew the front grille, bush off the air filters, and put the grille back on.
Key Features:
- 8 Ohms x 2: 870W RMS
- 4 Ohms x 2: 1300W RMS
- 8 Ohms Bridged: 2600W RMS
- 4 Ohms Bridged: 3600W RMS
- Class H Technology
- Status and clip LEDs
- Thermal, overcurrent, DC and output short protect circuitry
- 2 x Speakon outputs
- 2 x XLR outputs to link other audio equipment
- 2 x XLR inputs
- Peak and protect LEDs
- Built-in switchable limiter
- Continuously variable speed fan
- Suitable for touring, rental and installation
Specifications:
Stereo Power Output:
- 8 Ohms x 2 870W RMS
- 4 Ohms x 2 1300W RMS
Bridged Mono Output:
- 8 Ohms 2590W RMS
- 4 Ohms 3600W RMS
- Inputs 2 x XLR
- Outputs 2 x XLR, 2 x Speakon
- Frequency Response 20Hz - 30KHz
- Topology Class H
- Sensitivity 0dBu (0.775Vrms)
- Input Impedance 20K Ohms
- Maximum Input Level 22dBu (9.7Vrms)
- Slew Rate >40V / us
- Crosstalk <-70dB
- Signal to Noise >100dB
- Protection Switchable Limiter, Thermal protect, Over-current protect, Output
- DC protect, Output short protect, Power on/off mute
- Display 4 segment LED
- Cooling Variable Speed Fan
- Dimensions 88 x 483 x 451mm
- Net Weight 24kg / 52.91lbs
- Gross Weight 26kg / 57.32lbs
$277.41
Original: $792.60
-65%Wharfedale CPD3600 2x 870-Watt Power Amplifier—
$792.60
$277.41Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Wharfedale CPD3600 2x 870-Watt Power Amplifier
The Wharfedale CPD3600 Power amplifier delivers 870W RMS per channel at 8 Ohms and 1300W RMS per channel at 4 Ohms; a suitable power for medium to large sized complete PA systems for mobile and fixed installation. In bridged mode at 4 Ohms the amplifier generates 3600W RMS. This huge power means the amplifier can also integrate itself with larger touring rigs and installs where long throw, extremely high power audio is needed.
Technology
Working in stereo, parallel and bridged modes CPD3600 is built for a multitude of sound system formations. Brand new class H topology has resulted in a dynamic, high headroom amp made for propelling your loudspeakers through thick and thin with complete clarity.
Precision Control
Large rotary dials accurately adjust gain levels, and you will know when to do so from the clear and simple front panel. A 4 segment led formation displays shows vital power status, level, limit and protect information, keeping the sound engineer in the know.
Easy Cleaning
Amplifiers often work in hot and dusty environments and, over time, the fans of an amplifier can easily suck this in. Dirty cooling fans reduce efficiency and can lead to overheating. Its for this reason that Wharfedale Pro made the CPD series easy to clean. Simply unscrew the front grille, bush off the air filters, and put the grille back on.
Key Features:
- 8 Ohms x 2: 870W RMS
- 4 Ohms x 2: 1300W RMS
- 8 Ohms Bridged: 2600W RMS
- 4 Ohms Bridged: 3600W RMS
- Class H Technology
- Status and clip LEDs
- Thermal, overcurrent, DC and output short protect circuitry
- 2 x Speakon outputs
- 2 x XLR outputs to link other audio equipment
- 2 x XLR inputs
- Peak and protect LEDs
- Built-in switchable limiter
- Continuously variable speed fan
- Suitable for touring, rental and installation
Specifications:
Stereo Power Output:
- 8 Ohms x 2 870W RMS
- 4 Ohms x 2 1300W RMS
Bridged Mono Output:
- 8 Ohms 2590W RMS
- 4 Ohms 3600W RMS
- Inputs 2 x XLR
- Outputs 2 x XLR, 2 x Speakon
- Frequency Response 20Hz - 30KHz
- Topology Class H
- Sensitivity 0dBu (0.775Vrms)
- Input Impedance 20K Ohms
- Maximum Input Level 22dBu (9.7Vrms)
- Slew Rate >40V / us
- Crosstalk <-70dB
- Signal to Noise >100dB
- Protection Switchable Limiter, Thermal protect, Over-current protect, Output
- DC protect, Output short protect, Power on/off mute
- Display 4 segment LED
- Cooling Variable Speed Fan
- Dimensions 88 x 483 x 451mm
- Net Weight 24kg / 52.91lbs
- Gross Weight 26kg / 57.32lbs
